Montigo L38FSD, L42FSD, L52FSD Phenom Legacy L Series
The Phenom See Through – the standard of excellence in linear fireplace design. The Phenom Legacy L Series is a see through direct vent fireplace characterized by a landscape viewing area and linear flame. Rock or tile can be installed over the firebox frame for a clean minimalist look.
FEATURES
- Clean face design
- Snap-lock door for access to the firebox
- Remote flame level adjustment
- Convertible to top or rear flue vent
- IPI Electronic Ignition
- Full feature Proflame 2 remote control
- Remote controlled fans
- Concealed ribbon burner, reflective black porcelain panels, up-lighting + firestones.
SPECIFICATIONS
| L38FSD | L42FSD | L52FSD | |
|
Max BTU (NG) |
27,000 | 34,000 | 40,000 |
| Framing Width | 41 | 45 | 59 |
| Framing Height | 40 | 40 | 39 |
| Framing Depth | 23 ¾ | 23 ¾ | 23 ¾ |
| Glass Opening Width | 35 ¼ | 39 ½ | 47 |
| Glass Opening Height | 18 | 20 ¼ | 21 ¾ |
| Inner Vent Size | 5 | 5 | 5 |
| Outer Vent Size | 8 | 8 | 8 |
| Commercial | No | No | No |
| Customizable | No | No | No |
