Empire Hearth 36" Tahoe Premium Direct Vent Traditional Fireplace DVP36FP

Overview

Empire Hearth 36" Tahoe Premium Direct Vent Traditional Fireplace DVP36FP

Madison Premium Fireplaces include a tempered glass view window and a four-piece log set, mounted atop our legendary Slope Glaze Burner for a rich flame pattern within a taller, deeper log stack that complements the deeper fireplace (20 inches).

Liner options for Premium Models include: Aged Brick, Herringbone, Stacked Fieldstone, and Black Reflective.

Madison Premium Fireplaces are available in Millivolt, and in Green Earth Preferred Intermittent Pilot and Multi-Function Remote Control models.

Features

• Tempered Glass: 22 x 32 1/2
• Top Venting: 4" x 6 5/8" (Refer to manual for venting requirements)
• Framing 37 3/4" H x 39 3/8" W x 19 7/8" D (see manual before framing)

Includes:

• Log Set

Requires:

• Fireplace Barrier or Door Set and Frame with Barrier

Specifications

• Fuel Type: Gas
• Unit Type: Indoor
• Unit Size: 36"
• Viewing Area:  22" x 32-1/2"
• Style: Square - Traditional - Zero-Clearance
• Height without standoffs: 34-3/4 inches; framing height 37-3/4 inches.
• Width: 39 inches; framing width 39-3/8 inches.
• Depth and minimum framing depth: 19-7/8 inches.
• BTU input: Natural gas 18,000–25,000 BTU/h; propane 21,000–27,000 BTU/h. Minimum input values apply to millivolt models.
• Venting Style: Direct Vent
• Vent location: Top vent; rear vent installation is permitted only for natural-gas models, subject to the manual’s configuration limits.
• Venting Size: 4" x 6 5/8"

View manufacturer product video

View manufacturer product video

Manufacturer installation and operating instructions

DVP36FP installation instructions and owner’s manual — 39358-3-1019

Use the exact fuel and control model on the appliance rating plate. This manual provides the model-specific installation, venting, barrier-screen, gas-conversion, operation and service instructions. Installation must follow the manufacturer instructions and applicable codes.
