Majestic SL1100 6" Wood Chimney Pipe Section SL1106

SKU / Model: SL1106

Ask a question
Fast Shipping · Free on orders $300+
In-stock items are processed in 1–2 business days.

$113.00

YOUR SPECIAL OFFER IS AVAILABLE

This product qualifies for an exclusive special offer.

Complete your selections and add this product to your cart to unlock the eligible offer.

Offer eligibility and final promotional pricing are confirmed in the cart. Accessories qualify separately. Offers may change.
HHT 6" chimney section SL1106

Product overview

The SL1106 is a 6" long section of HHT SL1100 Series factory-built chimney pipe, used to build the vertical chimney above Majestic wood-burning fireplaces such as the Biltmore BILT36/BILT42 and Ashland ASH42. It is a venting component, not a fireplace.

SL1100 pipe has an 11" (279 mm) inside diameter and a 13" (330 mm) outside diameter. Because sections overlap at each joint, a 6" section adds 4-3/4" (121 mm) of effective height, which is the figure to use when planning total chimney height.

Specifications

Manufacturer part number SL1106
Series HHT SL1100 Series wood chimney
Actual length 6" (152 mm)
Effective length 4-3/4" (121 mm)
Inside / outside diameter 11" (279 mm) / 13" (330 mm)
Canadian equivalent SL406 (SL400 Series)
Verified fireplace compatibility Majestic BILT36, BILT42 (4013-920); ASH42 (4059-915)

Installation and safety notes

Per the BILT36/42 manual the chimney system must be at least 18 ft (5.49 m) tall straight (18.5 ft with one offset/return), with a 90 ft (27.43 m) maximum; keep a 2" (51 mm) air space between the chimney and all combustibles and insulation.

Sections lock together; pull up on each section after joining to confirm engagement. The manual notes sections cannot be taken apart once locked, so plan the layout before assembly. Support straight vertical runs at least every 35 ft (10.7 m).

Exact-model manuals and downloads

Majestic Biltmore BILT36/BILT42 Woodburning Fireplace Installation Manual, 4013-920 Rev F: pages 17 and 39–40 list SL1106 with actual and effective lengths

Majestic Ashland ASH42 Installation Manual, 4059-915 Rev T (10/24): page 37–38 chimney component list includes SL1106

Frequently asked questions — SL1106

Which Majestic fireplaces use the SL1106?

The BILT36/BILT42 manual (4013-920) and the ASH42 manual (4059-915) both list SL1106 in their SL1100 Series chimney components. Always confirm against the installation manual for your exact model.

How much height does one SL1106 add?

4-3/4" (121 mm) of effective height. The 6" figure is the actual length; the joint overlap reduces the usable height.

What diameter is SL1100 pipe?

11" (279 mm) inside diameter and 13" (330 mm) outside diameter, per the Biltmore manual.

Can I use it in Canada?

The Biltmore manual lists SL406 as the Canadian (SL400 Series) equivalent and states SL400 pipe is for Canada only. Use the series your manual specifies for your country.
